CAPABILITIES
MixUniX Laboratory



The research scope of the MixUniX Laboratory includes power measurement, flow field analysis, material characterization, and the development of integrated skid-mounted systems. In addition to standard laboratory instruments, the lab is equipped with advanced devices such as Particle Image Velocimetry (PIV), Brookfield viscometers, rheometers, and laser particle size analyzers to support specialized mixing studies.


The laboratory currently operates cold-model and hot-model platforms ranging from milliliter to cubic-meter scale, and offers a wide range of impeller types to support diverse mixing investigations across various process conditions and materials.

01
Multi-module Continuous Reactor Testing Platform
greatwall-mixers-agitator-dynamic-balance-test
02
Magnetic Self-priming Reactor Testing Platform
greatwall-mixers-mixing-simulation-experiment
Computational Fluid Dynamics (CFD)

Computational Fluid Dynamics (CFD) can replicate flow patterns within vessels and process setups without being limited by scale, allowing reliable prediction of the mixing performance of large tanks, including those with unique geometries or specific process requirements.


The MixUniX R&D team has extensively applied CFD across a wide range of process scenarios, from simple single-phase mixing to complex multiphase suspensions and dispersions. This approach not only addresses a variety of challenging technical problems for customers but also provides robust numerical simulation capabilities that underpin and accelerate product development.

great-wall-mixers-wastewater-treatment-cfd-flow-simulation
great-wall-mixers-wastewater-treatment-cfd-flow-simulation-1
great-wall-mixers-wastewater-treatment-cfd-flow-simulation-2
great-wall-mixers-fermentation-tank-cfd-flow-simulation
great-wall-mixers-fermentation-tank-cfd-flow-simulation-1
great-wall-mixers-fermentation-tank-cfd-flow-simulation-2
Load/No-Load Test

MixUniX provides load and no-load testing services for mixers. All testing procedures are conducted in strict accordance with applicable standards to ensure objective, accurate analysis and reliable recommendations.


The 29,000‑gallon (~110 m³) test tank accommodates mixers with motor power up to 250 HP (200 kW), shaft lengths up to 17.2ft (5.4 m), and impeller diameters up to 16.4 ft (5 m). It supports simultaneous testing of up to four mixer units and is equipped with an underwater camera system for real‑time monitoring of current, voltage, noise, speed, and vibration.


The no-load test platform supports mixers with shaft lengths up to 45.9 ft (14 m) and impeller diameters up to 26.4 ft (8 m).


By performing both no‑load and load tests prior to shipment, potential issues in design or manufacturing can be identified and resolved, ensuring the reliability of the delivered equipment.

great-wall-mixers-large-rooftop-no-load-test-platform
great-wall-mixers-mixer-assembly-inspection
great-wall-mixers-large-scale-water-test-platform
Mixer Design Selection Process and Design Software

In mixer selection and design, MixUniX has established a comprehensive management and design software framework. Its proprietary design software not only incorporates a wide range of proven engineering calculation formulas but also integrates nearly three decades of valuable design expertise inherited from Greatwall Mixers. These field-validated insights provide highly valuable technical support and scientific guidance for the development of new mixer designs.

great-wall-mixers-management-design-software
Obtain design data Including container parameters, material parameters, operating parameters, and process requirements
Technical communication Small-scale tests or computational fluid dynamics (CFD) analysis can be conducted as needed
Determine the type and speed of the mixer according to the process requirements
Draw the final design drawings
Mechanical design for mixer shaft strength and installation
Determine the motor power and select the matching reducer or seal
